REMOTE SYSTEM
SCOTT TwinLoc Suspension System
3 modes front and rear / integ. Grip clamp
DRIVE UNIT
Bosch Performance CX
EU: 25kmh / US: 20mph
BATTERY
PowerTube 625Wh
DISPLAY
Bosch Purion
CHARGER
4A Charger
REAR DERAILLEUR
SRAM SX Eagle / 12 Speed
SHIFTERS
SRAM SX Eagle Single Click
CRANKSET
FSA CK-320 / 165mm / 34T
CHAINRING
SRAM Eagle 34T DM / Steel
CHAIN
SRAM SX Eagle
CASSETTE
SRAM PG1210 / 11-50 T
BRAKES
Shimano BR-MT420 4 Piston
ROTOR
Front: SM-RT30 CL 203mm / Rear: RT-EM300 CL 203mm
HANDLEBAR
Syncros Hixon 2.0 Rise / Alloy 6061D.B.
20mm rise / 8° / 760mm
Syncros Comfort lock-on grips
H'STEM
Syncros FL2.0 / 6061 Alloy
L-Shape Spacer & Top Cap / 31.8mm / 6° / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5
31.6mm / S size 100mm / M 125mm / L & XL 150mm
SEAT
Syncros ER2.5
HEADSET
Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8"
OD 52/62mm / ID 44/56mm
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula CL-148S / Boost 148x12mm
SPOKES
Stainless Black
RIMS
Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready
FRONT TIRE
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead
EXO
Dual
REAR TIRE
Maxxis Rekon / 29x2.6" / 60TPI Wire Bead
EXO
Dual
LIGHTS
Bosch Light Cable pre-installed F&R
APPROX WEIGHTS IN KG
23.30
APPROX WEIGHTS IN LBS
51.37
MAX. SYSTEM WEIGHT
128 kg
The overall weight includes the bike
the rider
the equipment
and possible additional luggage.
